Double-Layer HDI Printed Circuit Board with Gold-Plated Finish and Customizable Design for High-Density Applications

Name: Double-Layer HDI Printed Circuit Board with Gold-Plated Finish and Customizable Design for High-Density Applications
Brand: Guangdong HongQi Advanced Materials Co., Ltd.
SKU: HQ00513
Availability: InStock

Brand Name:	HONGQI
Model Number:	HQ00513
MOQ:	1000PCS
Price:	negotiable
Delivery Time:	8-15 working days
Payment Terms:	L/C,D/A,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

GuangDong,China

Certification:

UL E477885 IATF16949 GB/T13485

Plate Thickness:

0.25mm±0.05

Mechanical Rigidity:

Flexible

Led Type:

SMD 2835

Smp:

Support

Smt And Dip:

Support

Led Quantity:

60pcs/m

Copper:

1oz

Soldmask:

White

Other Servuce:

Support Customized Services

Marketing Method:

Factory Direct Sales

Base Material:

Aluminum Base Laminate

Waterproof:

Yes

Operating Temperature:

-20℃ To 60℃

Thickness:

0.1mm

Voltage:

12V

Packaging Details:

Packed with strong Paper cases

Supply Ability:

100000 Pieces per month

Highlight:

custom FPCB circuit boards

FPC flexible flat cables

HDI printed circuit boards

Product Description

Ribbon-Connected Flexible Printed Circuit (FPC)

High-density HDI printed circuit board designed for seamless integration in electronic modules and communication devices.

Product Specifications

Product Model: HQ00513
Product Name: Ribbon-Connected Flexible Printed Circuit (FPC)
Features: Double-sided yellow solder mask, gold-plated finish, double-layer board structure
Customizable specifications and sample fabrication available

FPC Design Parameters

Dimensional Specifications

Precision FPC: Maximum size: 240*500 mm (limit: 250*500 mm); minimum size: no restriction
Roll Material Board: Maximum width: 240 mm; maximum length: 100 meters

Board Layer Count

Single-Layer Board: Simple structure for industrial control and electronic instruments
Double-Layer Board: Two copper foil layers with increased vias for mobile phones and automotive instruments

Solder Mask Color Options

Yellow: Recommended for most products including various cable applications
Black: For high-end or light-absorbing products like automobiles and mobile phones
White: With additional white coating for lighting fixtures and medical aesthetics equipment

Copper Foil Thickness

Board Type	Layer Count	Thickness Options
Precision FPC	Single-layer	18 μm (0.5 oz) or 35 μm (1 oz)
Precision FPC	Double-layer	12 μm (0.33 oz), 18 μm (0.5 oz), or 35 μm (1 oz)
Ordinary FPC	Single-layer	18 μm, 25 μm, 35 μm (1 oz), or 50 μm
Ordinary FPC	Double-layer	18-25 μm, 25-25 μm, 35-35 μm, or 35-70 μm

Minimum Line Width/Line Spacing

Recommended minimum of 3 mil for optimal manufacturing efficiency and quality.

Professional Service Process

Consulting & Technical Support

16 years of FPC design expertise with personalized solutions, design drawings, and new product development support.

Competitive Quotation

Consistent technology, high-quality materials, and advanced processes with cost-effective pricing for samples and batch orders.

Professional Production Capacity

Advanced equipment from Germany, Japan, and Taiwan. Factory covers 20,000 square meters with 800+ employees and 50 senior technical experts.

Integrated Design Service

One-stop services including substrate production, wiring design, schematic design, mold making, SMT, DIP, and stencil fabrication with international certifications.

Sample Fabrication

Specialized FPC sample customization with expedited production - double-layer flexible circuit board samples completed within 5-7 days.

Certificates & Honors
