Custom FPC LED Display PCB Design

Double Layer FPC
January 30, 2026
Category Connection: Double Layer FPC
Chat Now Contact Us
Tags:
#LED Printed Circuit Board #FPC Circuit Board #Flexible PCB Manufacturing
Brief: In this video, our team walks you through how the idea of a custom FPC LED display PCB performs in common scenarios. You'll see a detailed explanation of the design process for a double-layer flexible printed circuit board, including material selection, layer configuration, and key technical parameters for LED advertising applications.
Related Product Features:
  • Features a double-layer circuit board with double-sided black film and surface gold-plating for enhanced durability.
  • Offers excellent flexibility and resistance to bending, verified through tens of thousands of tests.
  • Available in various copper foil thicknesses including 12um, 18um, 25um, 35um, and 50um to suit different needs.
  • Supports customization of material thickness and process requirements for single, double-sided, and multi-layer FPCs.
  • Provides multiple solder mask color options including yellow, black, and white for different application requirements.
  • Maximum board dimensions of 240x500mm for precision FPC and roll material up to 240mm wide by 100 meters long.
  • Professional design services including substrate production, wiring, principle design, and one-stop manufacturing solutions.
  • Rapid sample production with dual panel samples completed within 5-7 days using expedited production lines.
FAQs:
  • What are the main advantages of using a double-layer FPC for LED displays?
    Double-layer FPCs feature two layers of copper foil with increased vias, creating more complex conductive paths. This makes them ideal for advanced applications like LED displays, mobile phones, and automotive instruments where higher circuit density and reliability are required.
  • How do you ensure the flexibility and durability of your FPC LED display panels?
    We conduct rigorous quality control using professional bending testers, performing tens of thousands of bending tests on each batch of materials before mass production. This ensures our FPCs maintain good flexibility and resistance to bending while meeting durability standards.
  • What customization options are available for FPC LED display PCB design?
    We offer comprehensive customization including material thickness selection, layer count (single, double, or multi-layer), copper foil thickness options from 12um to 70um, solder mask colors (yellow, black, white), and various board dimensions up to 240x500mm for precision FPC or roll materials up to 100 meters long.
  • What is your typical turnaround time for FPC LED display panel samples?
    We maintain expedited production lines specifically for sample making. For flexible circuit board dual panel samples, we can typically complete production within 5-7 days, allowing for quick prototyping and design validation.
